Celestron ASTROMASTER 70 mm AZ TELESCOPE 900mm focal length 1.25 inch tripod


Add Omni 2x barlow rs 2500

Add 3x barlow extra at rs 3000

or 32mm plossl-rs 3500 for deep sky

Bag-rs 2000

let us know at 9899212222 ; 9560687095



  • 70mm Refractor OTA
  • 900mm Focal Length, f/13 Focal Ratio
  • Anti-Reflection Fully Coated Optics
  • 1.25" Rack-and-Pinion Focuser
  • 10mm and 20mm Eyepieces
  • Manual Alt-Azimuth Mount
  • Altitude Control Handle
  • 90° Erect-Image Diagonal
  • StarPointer Red-Dot Finder
  • Adjustable-Height Stainless Steel Tripod

Celestron designed the AstroMaster 70AZ 70mm f/13 Alt-Az Refractor Telescope as a multi-function starter-scope that can be used for both astronomical and terrestrial viewing. Its medium aperture and long focal length allow it to draw in a generous amount of light with a high magnification potential to allow observation of the larger planets and the moon. The included 90° diagonal has an integrated erecting prism that corrects the view to enable the scope's use on land. Celestron includes two eyepieces for high and medium magnifications.The AstroMaster is outfitted with a manual alt-azimuth mount and to make finding and tracking objects easy, there is an altitude control handle and an azimuth lock. Supporting the mount and optical tube is a stainless steel tripod with sturdy 1.25" diameter legs and an adjustable height from 24 to 41-inches. Its center accessory tray pulls double-duty as a convenient place to eyepieces and smartphones while it locks the legs in place to improve stability and reduce vibrations.Optical Tube


  • 70mm aperture
  • f/13 focal ratio
  • 900mm focal length
  • Anti-reflection fully coated optics improve light transmission, color rendition, and contrast
  • Resolution: Rayleigh: 1.99 arcsec; Dawes: 1.66 arcsec
  • Rack-and-pinion focuser with 1.25" drawtube
  • Dovetail plate allows OTA to be attached to mount quickly and without tools

Mount and Tripod Mount:


  • Manual alt-azimuth
  • Control handle helps to adjust altitude
  • Azimuth lock reduces vibration and additional movement
  • Dovetail saddle accepts OTA plate



  • 1.25" stainless steel legs
  • Adjustable height from 24-41"
  • Accessory tray locks in-place for added stability and vibration reduction
  • Spiked feet provided additional stability on soft, rough, or uneven ground

Eyepieces and Accessories Eyepieces:


  • 1.25" diameter barrels accept most astronomical filters
  • 10mm produces 90x magnification
  • 20mm yields 45x power



  • 90° angle places user's head in a comfortable viewing position
  • Built-in erecting prism corrects view for terrestrial use as a conventional spotting scope
  • 1.25" barrel and eyepiece holder

StarPointer Finderscope:


  • Unmagnified to provide and exceptionally wide field of view to make finding subjects fast, and star-hopping navigation easy
  • Projects a center aiming dot that won't obscure the subject
  • Variable intensity center dot won't affect night-adjusted vision

Celestron AstroMaster 70 AZ Specs

Optical DesignRefractorAperture70 mmFocal Length900mmFocal Ratiof/13Eyepiece Barrel Diameter1.25"Diagonal90° erect-imageFinderscopeStarPointer red-dotTripod1.25" stainless steel legs
Adjustable height: 24.0 - 41.0" / 61.0 - 104.0 cmMount TypeManual alt-azimuthPower SourceNoneOptical Tube Length36.0" / 91.0 cmWeight18.0 lb / 8.2 kgMotorNoGO-TO CapabilityNoPC CompatibleNoOptical Lens Diameter2.6" (70mm)Maximum Useful Magnification130xResolving PowerNot Specified by ManufacturerPackaging InfoPackage Weight20.3 lbBox Dimensions (LxWxH)38.0 x 14.5 x 9.5"
